ناموجود
۲ عدد DDR4 DIMM sockets supporting up to 32 GB of system memory
Dual channel memory architecture
Support for DDR4 2666/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
To support 2666 MHz or XMP memory, you must install a 9th or 8th Generation Intel Core i9/i7/i5 processor
یک عدد
3 عدد
Realtek GbE LAN chip (10/100/1000 Mbit)
Realtek ALC887 codec
6 فاز
Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver
Support for S/PDIF Out
کانکتور برق اصلی 24 پبن ATX
4 عدد
۱ عدد Clear CMOS jumper
۱ مسیر PCI Express x16 slot, running at x16 (PCIEX16)
۲ مسیر PCI Express x1 slots
۳ مسیر PCI slots
SATA 3.0
۱ عدد PS/2 keyboard/mouse port
۱ عدد parallel port (LPT)
۱ عدد serial port (VGA)
۱ عدد D-Sub port
۱ عدد D-Sub port
۲ عدد USB 3.1 Gen 1 ports
۴ عدد USB 2.0/1.1 ports
۱ عدد RJ-45 port
۳ عدد audio jacks
ندارد
ندارد
۲ عدد 128 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
۱ عدد D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz
۱ عدد HDMI port, supporting a maximum resolution of 4096×2160@30 Hz
– Support for HDMI 1.4 version and HDCP 2.2
Maximum shared memory of 1GB
۱ عدد CPU fan header
۱ عدد system fan headers
۱ عدد front panel header
۱ عدد front panel audio header
۱ عدد S/PDIF Out header
۱ عدد USB 3.1 Gen 1 header
۱ عدد USB 2.0/1.1 header
۱ عدد Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)
۴ عدد USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
۶ عدد USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
۱ عدد M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support)
۴ عدد SATA 6Gb/s connectors
یک عدد
یک عدد
سه عدد
ندارد
یک عدد کومبو
یک عدد
ATX
یک عدد
دو عدد
DDR4
32 گیگابایت
چهار عدد
یک عدد
دو عدد
16 مسیر
چهار عدد
یک عدد
دو کاناله
Intel LGA 1151
Intel H310
Support for 9th and 8th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package
L3 cache varies with CPU
دو عدد
نقاط کنترل ولتاژ
DDR4 2666/2400/2133 مگاهرتز
۱ مسیر PCI Express x16 slot, running at x16 (PCIEX16)
۲ مسیر PCI Express x1 slots
۳ مسیر PCI slots
یک عدد
