حافظه | ۴ عدد DDR4 DIMM sockets supporting up to 128GB (32GB single DIMM capacity) of system memory
Please note that the support for system total memory size depends on the CPU installed
Dual channel memory architecture
Support for DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
|
نوع تخصیص مسیر | ۱ مسیر PCI Express x16 slot, running at x16 (PCIEX16)
۲ مسیر PCI Express x16 slots, running at x4 (PCIEX4_1/PCIEX4_2)
۳ مسیر PCI Express x1 slots
|
فرم فاکتور | ATX
|
اسلات PCI Express x16 | سه عدد
|
اسلات PCI Express x1 | سه عدد
|
نوع حافظه پشتیبانی شده | DDR4
|
حداکثر حافظه پشتیبانی شده | 128 گیگابایت
|
کانکتور SATA 3.0 | شش عدد
|
کانکتور M.2 | یک عدد
|
پورت USB 3.1 | شش عدد
|
تعداد سوکت پردازنده | یک عدد
|
پورت PS/2 | یک عدد برای ماوس
|
پیکربندی حافظه | دو کاناله
|
نوع سوکت پردازنده | Intel LGA 1151
|
چیپست | Intel Z390
|
پردازندههای پشتیبانی شده | Support for 9th and 8th Generation Intel Core i9 processors/Intel Core i7 processors/Intel Core i5 processors/Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1151 package
L3 cache varies with CPU
Intel Z390 Express Chipset
|
تعداد اسلات حافظه | چهار عدد
|
قابلیتهای مادربورد | نقاط کنترل ولتاژ
|
استانداردهای حافظه | DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 مگاهرتز
|
پشتیبانی از Crossfire | دو مسیره
|
پورت LAN | یک عدد
|
دکمهها | ندارد
|
مجموع کانکتور فن | 4 عدد
|
نوع اسلات M.2 | PCI-E 3.0 x4
|
پشتیبانی از RAID | RAID 0
|
جک 3.5 میلیمتری | 3 عدد
|
کارت شبکه LAN | Realtek GbE LAN chip (10/100/1000 Mbit)
|
کارت صدا | Realtek ALC887 codec
|
برد تغذیه | 12 فاز
|
توضیحات کارت صدا | Realtek ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver
Support for S/PDIF Out
|
کانکتورهای برق | کانکتور برق اصلی 24 پبن ATX
|
دکمهها، سوییچها و جامپرها | ۱ عدد Clear CMOS jumper
|
سایر توضیحات مربوط به اسلاتها | ۱ مسیر PCI Express x16 slot, running at x16 (PCIEX16)
۲ مسیر PCI Express x16 slots, running at x4 (PCIEX4_1/PCIEX4_2)
۳ مسیر PCI Express x1 slots
|
تعداد مسیرهای PCI Express | 24 مسیر
|
توضیحات تکمیلی پورتها | ۱ عدد PS/2 mouse port
۱ عدد PS/2 Keyboard port
۱ عدد HDMI port
۶ عدد USB 3.1 Gen 1 ports
۱ عدد RJ-45 port
۳ عدد audio jacks
|
تعداد هدر USB 3.1 Type-C | ندارد
|
تعداد هدر USB 3.2 Type-C | ندارد
|
سایر توضیحات بایوس | ۱ عدد 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
سایر توضیحات کارت گرافیک | Onboard Graphics
– Integrated Graphics Processor-Intel HD Graphics support
– ۱ عدد HDMI port, supporting a maximum resolution of 4096×2160@30 Hz
– Support for HDMI 1.4 version and HDCP 2.2
– Maximum shared memory of 1 GB
– Actual support may vary by CPU
Multi-Graphics Technology
– Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies
|
توضیحات پنل اورکلاک | DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules
|
توضیحات تکمیلی هدرها | iTE I/O Controller Chip
۱ عدد CPU fan header
۱ عدد system fan headers
۱ عدد RGB LED strip header
۱ عدد front panel header
۱ عدد front panel audio header
۱ عدد USB 3.1 Gen 1 header
۱ عدد USB 2.0/1.1 header
۱ عدد S/PDIF Out header
۱ عدد Thunderbolt add-in card connector
۱ عدد Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)
۱ عدد serial port header
|
توضیحات تکمیلی تمامی پورتهای USB مادربرد | ۸ عدد USB 3.1 Gen 1 ports (6 ports on the back panel, 2 ports available through the internal USB header)
۲ عدد USB 2.0/1.1 ports available through the internal USB header
|
هدر USB 2.0 | یک عدد
|
توضیحات تکمیلی قسمت ذخیرهسازی (Storage) | ۱ عدد M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
۶ عدد SATA 6Gb/s connectors
پشتیبانی از RAID 0, RAID 1, RAID 5, and RAID 10
xx Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors xx
Intel Optane Memory Ready
|
---|
